18.3 Type of Measurement
18.3.1 Vertical Measurement
Vertical measurement includes 19 parameters:
 Max: Highest value in the input waveform
 Min: Lowest value in the input waveform
 Pk-Pk: Difference between maximum and minimum data
values
 Top: Value of most probable higher state in a bimodal
waveform
 Base: Value of most probable lower state in a bimodal
