Sigma 2-6E - Using the Centrifuge; Description; Operating Elements

Version 04/2008, Rev. 1.18 of 07/06/2012 page 23 of 65
Translation of the original operating manual
5 Using the Centrifuge
5.1 Description
5.1.1 Operating Elements
Fig. 5.1: Total view of the centrifuge
Fig. 5.2: Rear view of the centrifuge
9
10
11
1 Mains power switch
2 Stop key
3 Lid key
4 Display
5 Lid
6 Start key
7 Left rotary knob
8 Right rotary knob
9 Name plate (see Fig. 5.4)
10 Equipotential bonding screw
11 Mains power input
1
3
2
7
8
4
5
6
