Sigma 980 - 980 Flow Meter Basic Programming Setup Flow Chart

Section 4
Page 93
Velocity-Only Sensor
Figure 40 Attaching the Sensor Mounting Band
Figure 41 Avoiding Silt when Mounting the Sensor
1. Receptacle for Spring Clip 2. Velocity Sensor 3. Nylon Wire Ties
1
2
3
1. Water 2. Silt 3. Pipe 4. Sensor
3
1
2
4
