Sigma DP3 Merrill User Manual

49
FOCUSING
Adjustment of autofocus and manual focus operation are
explained below.
FOCUS MODE
Each time the button is pressed, AF mode (without
an icon), AF Limit Mode (P. 52 ) and MF mode (
icon)
will alternate.
HOW TO USE AUTOFOCUS
Position the photographic subject within
the centre of the composition and press
the shutter button “half-way”.
 If autofocus is selected, the focusing point
will be illuminated in green. (At the same
time, the auto focus lamp will be
illuminated in green.)
 If autofocus cannot set correctly, the focusing point will blink. (At the same
time, the auto focus lamp will blink in red)
 The focusing distance is from 22.6cm to infinity.
Although your camera is equipped with highly precise AF system, in
some cases autofocus cannot set correctly.
 Low-contrast subjects, such as blue sky or a blank wall, etc. or when the
color of the subject is same as background
 The subject is located in a very low light environment
 Overlapping near and far objects, such as an animal behind a fence
 A subject, which moves at high speed
In such cases, please use one of the following focusing methods.
1. Use the Focus Lock function to focus on another subject, which has a
similar focusing distance as your subject.

Sigma DP3 Merrill Specifications

General

Megapixel	46 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG
Supported aspect ratios	3:2
Maximum image resolution	4704 × 3136 pixels
Still image resolution(s)	4704 × 3136, 3264 × 2176, 2336 × 1568, 4704 × 3136, 3264 × 2176, 2336 × 1568
Optical zoom	- x
Focal length range	2.8 - 16 mm
Minimum aperture number	-
Number of diaphragm blades	7
Lens structure (elements/groups)	10/8
Minimum focal length (35mm film equiv)	- mm
Normal focusing range	0.22 - ∞ m
Auto focusing (AF) modes	Spot Auto Focus
ISO sensitivity	100, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Auto Exposure (AE) lock	Yes
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	30 s
HD type	Not supported
Maximum video resolution	- pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	MMC, SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
USB version	2.0
Product color	Black
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Daylight, Flash, Fluorescent, Incandescent, Shade
Self-timer delay	2, 10 s
Power source type	Battery
Battery type	BP-41

Weight and Dimensions

Depth	80.6 mm
Width	121.5 mm
Height	66.7 mm
Weight	400 g
