Sigma DP3 Merrill User Manual

52
4
While pressing the shutter button halfway and rotating the Focus ring,
the display can be magnified. Adjust focus by rotating the Focus ring.
5
The enlarged display returns to normal one second after stopping
rotation of the Focus ring. Compose the image as desired and take the
picture.
 To return to normal AF mode, select [Off] in step 1 .
 The enlarged display will be magnified from the selected focusing
point of the LCD monitor by pressing
button. It is possible to set
the enlarged area to be the same as the focusing point selection. See
P. 50 for information regarding focusing point.
WARNING !!
 It is not possible to set AF+MF Mode when Face detection AF
mode setting is selected.
AF LIMIT MODE
The DP3 Merrill has an AF Limit Mode that can speed up the Auto
Focusing while limiting the focusing range. Four optional modes are
available and each is designed to offer a unique shooting function.
1
Press the button and select the
AF Limit mode.
(The icon of AF Limit Mode and the
scale bar will appear at the bottom of
the LCD display.)
 In case it does not switch to AF Limit Mode, set by selecting [
Capture Settings] (P. 28) → [AF Limit Mode] → [On].（AF Limit
mode will be added to the Focus mode.)

Sigma DP3 Merrill Specifications

General

Megapixel	46 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG
Supported aspect ratios	3:2
Maximum image resolution	4704 × 3136 pixels
Still image resolution(s)	4704 × 3136, 3264 × 2176, 2336 × 1568, 4704 × 3136, 3264 × 2176, 2336 × 1568
Optical zoom	- x
Focal length range	2.8 - 16 mm
Minimum aperture number	-
Number of diaphragm blades	7
Lens structure (elements/groups)	10/8
Minimum focal length (35mm film equiv)	- mm
Normal focusing range	0.22 - ∞ m
Auto focusing (AF) modes	Spot Auto Focus
ISO sensitivity	100, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Auto Exposure (AE) lock	Yes
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	30 s
HD type	Not supported
Maximum video resolution	- pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	MMC, SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
USB version	2.0
Product color	Black
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Daylight, Flash, Fluorescent, Incandescent, Shade
Self-timer delay	2, 10 s
Power source type	Battery
Battery type	BP-41

Weight and Dimensions

Depth	80.6 mm
Width	121.5 mm
Height	66.7 mm
Weight	400 g
