C-DIAS PROCESSOR M
ODULE
CCP 531
Page
16
12
.0
4.2017
C1 ...
CAN PLC station
00
–
30 ... Sta
tion numb
er
C2 ... CAN PLC baud ra
te
00 ... 615.0
00
01 … 500.000
02 … 250.000
03 … 125.000
04 … 100.000
05 … 50.000
06 … 20.000
07 … 1.000.0
00
I1, I2, I3, I4
IP addres
s I1.I2.I3.I4
,
Hexadecimal
00
–
FF respe
ctively
S1,S2,S3,S4 Subn
et Mask S1.S2.S3.S4, he
xa-
decimal
00
–
FF respe
ctively
G1,G2,G3,G4 Gateway G1,G2.G3.G4, hexadec-
imal
00
–
FF respe
ctively
a
15
17
Table of Contents
Technical Data
2
Performance Data
2
Environmental Conditions
4
Mechanical Dimensions
5
Connector Layout
6
Status Displays
11
CAN Bus Setup
13
CAN Bus Termination
17
Earth Connection
18
ESD Protection
19
Process Diagram
20
Status and Error Messages
22
