SIGMATEK CCP 621 User Manual

CCP 621 C-DIAS PROSESSOR MODULE
Page 30 27.03.2020
15
STOP BRKPT
The CPU was stopped by a breakpoint in
the program.
16
CPU STOP
The CPU was stopped by the PG soft-
ware (F6 HALT in status test).
17
INT ERROR
The CPU has triggered a false interrupt
and stopped the user program or has
encountered an unknown instruction
while running the program.
Cause:
- - A non-existent operating system
command was used.
- Stack error (uneven number of
PUSH and POP instructions).
- - The user program was interrupted
through a software error.
Solution:
- Correct program error
18
SINGLE
STEP
The CPU is in single step mode and is
waiting for further instructions.
19
READY
A module or project has been sent to the
CPU and it is ready to run the program.
20
LOAD
The program is stopped and the CPU is
currently receiving a new module or
project.
21
UNZUL.
MODULE
The CPU has received a module that
does not belong to the project.
22
MEMORY
FULL
The operating system memory /Heap) is
too small. No memory could be reserved
while calling an internal or interface
function is called from the application.
23
NOT LINKED
When starting the CPU, a missing
module or a module that does not belong
to the project was detected.
24
DIV BY 0
A division error has occurred.
Possible Causes:
- Division by 0.
- The result of a division does not fit
in the result register.
Solution:
Correct program error
