SIGMATEK CCP 621 User Manual

C-DIAS PROCESSOR MODULE CCP 621
27.03.2020 Page 33
68
BACKGROUND RUNTIME
The total time for all background
objects exceed the maximum time;
the time can be configured using two
system variables:
- BTRuntime: time remaining
- SWBTRuntime: pre-selected value
for the runtime counter
70
C-DIAS ERROR
A connection error with a C-DIAS
module has occurred.
Cause:
- The cause of the error is
documented in the log file
Solution:
- This depends on the
cause
72
S-DIAS ERROR
A connection error with a S-DIAS
module has occurred.
Possible causes:
- real network does not
match the project
- S-DIAS client is defective
Solution:
- analyze logfile
75
SRAM ERROR
Only EDGE CPUs
An error occurred while initializing,
reading or writing SRAM data.
Possible causes:
- - SRAM configured incor-
rectly
- - SD card formatted
incorrectly
- - SD card removed
Solution:
- - evaluate log file
(Event00.log)
- - check configuration
- - format SD card as
EDGE medium with Lasal
Class 2
- - check SD card
95
USER DEFINED 0
User-definable code.
96
USER DEFINED 1
User-definable code.
97
USER DEFINED 2
User-definable code.
98
USER DEFINED 3
User-definable code.
99
USER DEFINED 4
User-definable code.
100
C_INIT
Initialization start; the configuration is
run.
