Page #11 background imageLoading...
Page #11 background image
C-DIAS SAFETY DIGITAL OUTPUT MODULE CSTO 082
1.5 Page 11
Technical Data
Output specifications
All Safety outputs are short-circuit protected and specified according to IEC/EN 61131. The
outputs are compatible with input of type 1, 2 and 3.
Number of …
8
Rated output voltage
+24 V DC
Output voltage range
minimum +18 V
maximum +30 V
Maximum output current per
channel
2 A
Maximum total current per
output group (2 outputs)
2 A
Maximum total current
(complete module)
8 A
up to a max. 45 °C
ext. temperature
6 A
up to a max. 50 °C
ext. temperature
4 A
up to a max. 55 °C
ext. temperature
Brake voltage with switching-off
inductive loads
typically 0.85 V
Maximum switch-off energy of
the outputs (inductive load)
maximum 0.4 Joule per channel
maximum 1.2 Joule (entire module)
Turn-on delay
< 200 µs
Turn-off delay
< 1 ms
Miscellaneous
short-circuit proof
Cut-off test signal
< 1.5 ms
Table 2: Input specifications
