C-DIAS SAFETY DIGITAL OUTPUT MODULE CSTO 082
1.5 Page 25
The following schematic shows the corresponding block diagram for the wiring in tabular
form.
Connection Diagram
Central wiring
Control configuration
CSCP 012
Con-
nectors
Pin
Connection
X2
1
Normally open start button S1 (B)
2
Normally open start button S1 (B)
3
Normally closed Emergency Stop S2 (A)
4
Normally closed Emergency Stop S2 (b)
X3
1
Output A
2
Clock output B
3
+24 V
4
GND
Central wiring
Control configuration
CSTO 082
Con-
nectors
Pin
Connection
X1
1
Control relay K1
2
Control signal light P1
3
---
4
---
X3
1
+24 V
2
+24 V
3
GND
4
GND
Table 10: Connection diagram example
