Signode tools and machines are
d
esigned and warranted to work together
with Signode strapping and seals. Use of
non-Signode strap, seals and/or
manufactured or specified replacement
parts may result in strap breakage or
joint separation while applying strapping
to a load or during normal shipping and
handling. This could result in severe
personal injury.
TABLE OF CONTENTS
G
eneral Safety Instructions 2
Specifications 4
Major Components 5
Installation 5
Maintenance 5
Pneumatic Information 6
Strap Tension 8
Operating Instructions 9
Parts List, Tool 12
Parts List, Gear Housing 14
Parts List, Air Motor 16
Declaration Of Conformity 19
PN2-114
Part No. 423500
(Patent No. 6,073,664)
PN2-2
Part No. 428360
(Patent No. 6,073,664)
SPECIFICATIONS
STRAP
MODEL TYPE WIDTH THICKNESS SEALS
PN2-114
Apex
&
Magnus
3/4"(19mm)
to
1-1/4"(31.75mm)
.020"(0.5mm)
to
.044"(1.12mm)
34HOC
114P
PN2-2 Magnus 2" (50mm) .044"(1.12mm) 208DG
