10
OPERATING INSTRUCTIONS
B
efore operating this tool, make sure it has been properly maintained as noted in the
Maintenance section of this manual.
Wear safety glasses. Always position yourself to one side of the strap. Make sure all
bystanders are clear before proceeding.
Failure to follow the above could result in severe personal injury.
1. Thread the strap through a Signode full overlap
push type seal. Encircle the bundle and
rethread the strap end through the seal as
shown. Bend the strap end back sharply under
the seal, about 2 ½ inches, and pull out the
slack strap.
! For 3/4" strap use #34HOC Seals.
! For 1-1/4" strap use #114P seals.
! For 2" strap use #208DG seals.
2. Press the gripper lever (A) with palm. Place the top strap into
the front nose opening and slide the tool forward until it butts
against the seal.
3. While standing to one side of the strap line, release the gripper
lever (A) and turn the air control ring (B) in the direction of the
arrow with the palm of the hand. The tool will automatically
tension the strap and hold it tight.
