16
PARTS LIST, AIR MOTOR 100L15, PART NO. 423510
KEY QTY. PART NO. DESCRIPTION
1 1 024631 Filter assembly
2
1 023557 Retainer, Spirolox, #RS-181
3 1 024676 Valve collar
4 1 024662
Valve stem
5 1 023559 O-ring
6 1 023549 Retainer
7
1 024663 Valve sleeve
8 1 004164
O-ring
9 1 423508 Motor housing
1
0 1 023372 Roll pin, 3/16 x 3/8
11 1 024661 Valve spring
12 1 423534 Deflector assembly
13 1 024633
Bearing, Fafnir, #ASIK7-SRI #2
14 1 024653 Back end plate
15 1 024652 Cylinder
1
6 1 423423
Rotor
17 5 024651 Vane
1
8 1 024602 Spacer
19 1 023510 Align pin
20 1 423794
Front end plate
2
1 1 023481 Ball bearing
22 1 023547 Ball bearing
24 1 423403 Idler carrier assembly
25 3 423060
Idler
26 1 423798 Ring gear
2
7 1 023558 Seal
28 1 423404 Spacer
29 2 423793 Bevel spring washer
30 1 306612 Pin
31 1 423795 Gear housing
33 1 286373 3 symbol safety sign
34 1 280537 On-Off label
! When ordering parts please indicate air motor model, part number and description.
! Recommended spare parts are underlined and should be stocked.
! Common hardware parts can be obtained at any local hardware supply.
NOTES:
1. Align marks on motor housing as indicated in “View A-A”.
2. Location of air motor number (underside).
3. Idler gears (25) are to be lubricated with Non-Fluid Oil #K55 or equivalent. Vanes (17)
must soak in air line oil overnight before assembling air motor.
4. If the rear motor housing (9) becomes loose, it must be retightened while the motor is
running at 20 to 30 psig (1.6 to 2.0 Bar) air pressure. This will ensure proper alignment
and rotor freedom.
5. Spring washers should be assembled back to back with cup shape facing outwards )( .
6. Apply labels (Key 33 & 34) to motor housing oriented as shown in “View B”.
