14
PARTS LIST, GEAR HOUSING ASSEMBLY, PART NO. 423520
K
EY
QTY. PART # DESCRIPTION
1 1 008781 Thrust washer
2
1 008872 Ring gear key
3 1 008871 Ring gear
4 1 008769 Spacer
5 3 008766
Idler gear
7 1 306389 Idler gear plate assembly
8
1 008756 Bearing, Fafnir 7203
9 1 008774 Key
10 1 423530 Worm
11 1 423511 Gear housing
12 1 008751 Needle bearing, Torr M781
13 1 008752 Truarc, N5000-62
14 1 423515 Bearing, Fafnir B539DD
15 1 024038 Bearing, Fafnir KP10A
16 1 423529
Worm - gear
17 1 423501 Feedwheel shaft
1
8 1 423509 Cover
19 1 250731 Truarc ring, N5000-185
20 1 256755 O-Ring, SAE 30
21 1 423531 O-Ring, SAE 18
22 1 423533 Thrust washer
! When ordering parts please show tool model, part number and description.
! Recommended spare parts are underlined and should be stocked.
! Common hardware parts can be obtained at any local hardware supply.
