10
OPERATING INSTRUCTIONS, Continued
CYCLING THE TOOL
1. Grasp the TOP STRAP and insert it sideways
into the tool between the feedwheel and the
breaker foot. Make sure the strap is in full
contact with the inside surface of the breaker
foot. When the TOP STRAP is properly loaded,
the sealing mechanism will be in line with the
seal.
2. Push the tool forward until the seal-stop
contacts the end of the seal.
Pull
back on the TOP STRAP to eliminate additional
slack around the package. You will have to
push on the cylinder cover to make certain that
the jaw tips are in position over the seal.
Note: Before continuing, make sure the TOP STRAP and the seal is still in position, as
described above. Note that the BOTTOM STRAP will be positioned in the channel on the
bottom surface of the breaker foot. This too, is necessary to maintain strap alignment during
tensioning.
3. While standing to one side of the strap, press
the operating lever all the way down and then
release it.
The air motor will turn the feedwheel and the
feedwheel will tension the strap around the
package until the present tension level has
been reached, at which time the air motor will
stall.
To Next Page
