4
Signode tools and machines are designed
and warranted to work together with
Signode strapping and seals. Use of non-
Signode strap, seals and/or manufactured
or specified replacement parts may result
in strap breakage or joint separation
while applying strapping to a load or
during normal shipping and handling.
This could result in serious personal
injury.
TABLE OF CONTENTS Page
General Safety Instructions 2
Specifications 4
Tool Installation 4
Major Components 5
Pneumatic Information 6
Strap Tension 8
Operating Instructions 9
Tool Adjustments 11
Troubleshooting 12
Parts List & Exploded Views 14
Declaration of Conformity 27
PRHR-34
Part No. 424234
PRHR-114
Part No. 423570
SPECIFICATIONS
MODEL
STRAP
SEALS
TYPE WIDTH THICKNESS
PRHR-34
MAGNUS
PAINT & WAX
3/4"
0.025" Minimum
0.031" Maximum
34P
PRHR-114* 1-1/4" 114P
* Refer to page 18 of this manual for information on 0.044" strap conversion.
TOOL INSTALLATION
To work effectively, the PRHR Tool must be properly installed. This installation includes, in
some cases, proper suspension of the tool over the container to be strapped and the proper
placement of the strapping dispenser to provide a continuous easy supply of strapping for the
application.
