influence the value displayed, eg.
tool correction value.
_dP_ Decimal point (only available if
'Resolution' has been programmed
to 'FrEE' before): Determination of
the decimal point according to the
resolution.
_dIr_ Counting direction of the measu-
ring system: depends on the
sensor’s mounting position and
can be changed subsequently.
"UP" Upward
"dn" Downward
_AUto_ Switch-off method: State of the
automatic switch-off:
"oFF" no switch-off.
"on" automatically switch-off
PErIod Switch-off time : Time since last
measurement / sensor move after
which the display will switch-off.
_rSto__ Last value memory:
"oFF" Last value memory off. When
switched on, the display must be
calibrated (zeroed).
"on" Last value memory on. When
switched on, the last measured
value is displayed.
_4_oFF Delayed switch-off:
ON/OFF key must be pressed for
approx. 4s to switch off the
display.
_F_AbS Access reset function: resetting to
reference value via key on
front of the display.
"oFF" Reset function off
"on" Reset function on
_F_rEL Access incremental measurement:
to switch from absolute dimension
and zero-setting to subsequent
relative dimension
"oFF" Increm. meas. function off
"on" Increm. meas. function on
_F_rEF Access reference value: to enter /
change reference value
"oFF" Reference value function off
"on" Reference value function on
_F_oFF Access offset value: to enter /
change offset value
"oFF" Offset value function off
"on" Offset value function on
_SPEEd To alter power consumption by
changing processor´s speed.
"HI" Full processor speed
"Lo" Reduced processor speed with low
power consumtion
_LAn_ Language: to choose the language
in which the menu points are to be
displayed
"d" German
"E" English
8. Input mode
Reset function via keyboard
• Press key to set the display to the reference
value.
Precondition: Parameter 'Reset enable'
(_F_AbS) in programming mode must be pro-
grammed to "on", but unit must not be left in
programming mode (see chapter 6 'To leave
programming mode').
Incremental measurement
Press the two arrow keys + simultaneously
to activate incremental measurement function.
• The display is zeroed.
• The Display shows the blinking
• Leave incremental measurement function by
another simultaneous press of the two arrow
keys + . The absolute measuring value is
displayed again.
• While in the incremental measurement mode-
the display can also be set to zero by pres-sing
key . This does not change the absolute
measurement in the background.
Precondition: Menu point 'Incremental measu-
rement enable' (_F_rEL) in programming mode
must be programmed to "on", but unit must not
be left in programming mode (see chapter 6 ‚'To
leave programming mode').
Reference and/or offset value modification
Press the two keys + simultaneously to
enter a new reference value.
Press the two keys + simultaneously to
enter a new offset value.
The display then shows the reference / offset
value, which can be changed via the two arrow
keys.
