Page 20
Usermanual Motors 902x_903x
9 Troubleshooting
... the motor doesn’t move?
Check if motor is correctly supplied with power according to the
wiring diagram and if the DIP switches are in the right position.
... the motor doesn’t move after saving the rst end stop?
Disconnect power supply. Start limit setting process again ensuring
that button 1 is used rst to drive the system to its rst limit position.
... the motor turns in the wrong direction with low voltage switching
(permanent power supply)
Exchange cable of Pin 2 with Pin 3 at the low voltage switch
terminal connection.
... the motor SG 9020 turns in the wrong direction with mains
switched connection?
Exchange cable of Pin 2 and 3 on mains plug.
... some motors 9020 / 9022 turn in the wrong direction when
connected for simultaneous operation using mains switching.
Check if Pin 2 and Pin 3 on each motor are connected identically.
10 Declaration of Conformity
Micro- Motor AG conrms herewith that this product complies with
the relevant harmonised regulations of the 73 / 23 / EEC + 89 / 336 /
EEC + 93 / 68 / EEC directives. The declaration of conformity can be
ordered at: info@micromotor.ch .
