Silent Sentinel Jaeger - Page 13

JAEGER INSTALLATION GUIDE
Commercial in Confidence 13/26
2
Insert the supplied O-Ring into the groove on the
wiper box.
3
Align the wiper assembly holes with camera house
jack plug holes
3
Screw the supplied M4x 50 screws into the QTY4
fixing holes. Ensure that the O’ring is seated
properly when screwing together
3
Insert the spring into the wiper assembely shaft.
