JAEGER INSTALLATION GUIDE
Commercial in Confidence 12/26
Wiper Assembly Installation
Overview
This guide details the steps involved to install the wiper assembly onto a RHT camera housing.
Fixtures and Fittings
1. Wiper Assembly
2. Wiper Blade
3. O-Ring
4. Fixings
Step
Detail
1
Power down the camera unit and remove the
bottom cover at the front of the camera housing.
