13AnalogNX2.doc Page 2 Latest update: 23 Jan -03
Technical specifications
Dimensions:
NX2 Analog instrument: 113 x 113 x 23+28 mm
(4,4 x 4,4 x 0,9 + 1,1 inch).
Instrument cable:
0,4 m (16 inch)
Power supply:
12V DC (10-16V). The instruments are polarity protected.
Power
consumption at 12 V:
70-90 mA at 12 V=0,8-1,1W
with maximum lighting: 140-160 mA at 12 V=1,7-1,9W
Temperature range:
Storage: -30° to +80°C (-22° to +176°F)
Operation: -10° to +70°C (14° to 158°F)
Weight:
260 gram (9,17 oz).
Enclosure:
All Analog instrument: Water proof acc. to IP 68/IP66
CE Approval:
The products conform to the EMC requirements for
immunity and emission according to EN 50 081-1.
