16RemoteNX2.doc Page 1 Latest update: 29 Jan -03
16. REMOTE CONTROL INSTRUMENT
Remote Control instrument can be connected directly to a NX2 instrument on the
Nexus Network, or to the NX2 Server, and you do not have to re-calibrate the
transducers or the current system set-up.
The Remote Control instrument is more than just a remote control.
• It is a NX2 Multi function instrument in itself, displaying all functions in the
Network.
• It can remote control all, or selected Nexus instruments in the Network.
• It can be used at the chart table as the waypoint and rout editor in the Network
• It can be an integrated control unit for the Nexus Autopilot.
• It offers unique trim functions for the sailor.
• It offers a Man Over Board function.
• It offers a built in alarm with eight alarm settings.
• It offers a control of the MAXI repeaters, up to nine units.
• It offers a control of the MULTI XL repeaters.
• It offers the possibility to customise the display with your two favourite functions.
• It can be configured to ”hide” pages you do not want to use, or conceal from
curious hands.
Service measures
The basic service measures on all NX2 Remote Control instrument are based on
Faultfinding, see §5, replacing defect units according to the NX2 Replacement
system
Technical specifications
Dimensions:
Instrument: 150 x 72 x 26 mm (5,9 x 2,8 x 1,0 inch).
Bracket: 110 x 79 x 28 mm (4,3 x 3,1 x 1,1 inch)
Instrument cable:
5 m (16 ft)
Power supply:
12V DC (10-16V). The instrument is polarity protected.
Power
consumption at 12 V:
13 mA at 12 V=0,15 W
with maximum lighting: 70 mA at 12 V= 0,8 W
Temperature range:
Storage: -30° to +80°C (-22° to +176°F)
Operation: -10° to +70°C (14° to 158°F)
Weight:
Instrument: 200 gram ( 7 oz).
Bracket: 20 gram (0,7 oz)
Enclosure:
Water proof
CE Approval:
The products conform to the EMC requirements for
immunity and emission according to EN 50 081-1 and EN
55022.
