Operating Elements
MP3/CD Car Radio KH 2382
GB
29
RESET:
Resetting the device
30
Theft protection LED
31
Positions LED of the CD
compartment
32
CD compartment
33
ISO block connection B
34
Automotive blade
type fuse 10 A
35
ISO block connection A
36
Securing screw
(incl. M5 nut and washer)
37
LINE OUT:
Audio cinch output L/R for
amplifi er
38
Antenna connection for
DIN antenna plug
39
POWER/DIM:
Switch device on and off /
dim display illumination
40
MUTE:
Switching off the sound
41
I◂◂:
Title / Station search
backwards
42
VOL+:
Volume increase
43
AS/PS:
Automatic station saving
44
▸▸I:
Title / Station search forwards
45
INT/3:
Intro function in the CD/
MP3 operation mode,
number button 3
46
VOL-:
Volume decrease
47
PTY:
Station search by PTY group
48
Number button 6
49
DSP:
Sound setting
50
BAND:
Select frequency range
51
Battery compartment
52
SEL:
Press or hold down to access
adjustment options
53
TA:
Activate traffi c radio station
54
AF:
Alternative frequency search
/ activate regional programmes
55
Number button 5
56
RDM/4:
Random playback in the CD/
MP3 operation mode/
number button 4
57
RPT/2:
Repeat function in the CD/
MP3 operation mode/
number button 2
58
▸II/1:
Playback start or stop/
number button 1
59
MODE:
Set operation type/
Loudness function
60
Case for face plate
61
Bezel frame
62
Installation bracket
63
Key for installation bracket
64
Fixture plate
(incl. securing material)
