Installation
MP3/CD Car Radio KH 2382
GB
To avoid function disturbances the installation angle should be less than 30°. ■
Do not install the device in a location where it will be subjected to high ■
temperatures(i.e. direct sunlight or heating vents), heavy contamination and
strong vibr
ations.
In the event that changes to the vehicle are necessary contact your vehicle
■
dealer/qualifi ed radio installation facility.
Installing the device into the ISO duct
Pull the installation bracket
62
and the bezel frame
61
from the device's
housing.
Place the installation bracket into the ISO mounting duct.
Bend the tabs on the installation bracket with a scr
e
w driver so that the bracket
is fi xed fi rmly into the mounting duct (see diagram).
Check to make sure that the bracket is securely fi xed.
Connect the ISO socket block of the device with the two ISO plugs on your
vehicle.
Connect the antenna cable from the v
ehicle antenna to the antenna socket
on the device.
Contingently connect the audio cinch cable of an external amplifi
er to the
LINE OUT socke
t
37
on the device.
