1. Overview
1 Filter for double espresso
2 Filter for single espresso
3 Water tank
4 Hot plate for cups
5 / OFF Dial for steam and hot water
6 Hose (for water tank)
7 Power cable with mains plug
8 Steam nozzle
9 Coffee spoon with tamper
10 Handle (on the steam nozzle)
11 Float (indicator: empty drip tray)
12 Drip tray
13 Brewing head
14 Drip grid
15 Symbol (front panel): indicates the position in which the portafil-
ter is locked
16 Symbol (left side of the device): indicates the position in which the
portafilter can be inserted and removed
17 Control elements (front panel)
18 Notch in the edge of the portafilter19
19 Portafilter
20 Nub on the side of the filter1/2
21 Notch in the edge of the filter1/2
