Appliance description
Figure A:
1 Appliance lid
2 Suction fitting
3 Lower sealing ring
4 Sealing wires
5 Cable storage compartment
6 Rear limiters
7 Front limiters
8 Lid release
9 Drip tray
0 Suction tube
q Storage compartment lid
w Upper sealing ring
e Press seal
Figure B:
r
button (switch appliance on/off) with control lamp (green)
t button (start "Sealing" function) with control lamp (red)
z button (start "Vacuum sealing" function) with control lamp (red)
u
button (activate/deactivate additional function "Wet")
with control lamp (green)
i button (activate/deactivate additional function "Soft")
with control lamp (green)
o
button (start/cancel "External vacuuming" function)
with control lamp (green)
p button (start "Marinate" function) with control lamp (green)
a button (cancel function/process) with control lamp (green)
Figure C:
s Vacuum hose
d Adapter A
f Adapter B
g Adapter C
