n Insert Ø10mm wall plugs into the holes drilled as A, B, C, and
D and screw down the screws at the points A + B, in such a
way as to remain 5mm space between the screw head and the
wall (Fig. 11)
n Hang it on the wall with the hanging plate of the cooker hood.
n Tighten A + B fixing screws on the wall, and completely secure
the product at point D, C.
INSTALLATION OF PRODUCT
Installation Scheme and Parts
28.12.2017HOOD USER GUIDE ENGLISH20
