14 LAMP REPLACEMENT
14.1 Halogen Lamp Replacement
WARNING!
Disconnect the electrical supply of the hood. Leave
the lamps to cool down first because they could
burn your hands when they are hot.
It indicates the maximum power consumption of the lamp. A lamp
with same power rating should be used when replacing the lamp.
To find out the power rating used in the product,
see the declaration label in the product.
Only self-protection tungsten halogen lamp or self-protection metal
halide lamp must be used.
For replacing the halogen lamps, push downwards on the lamp
holder from its behind, turn it a little bit counter-clockwise, and take
it out downwards.Fig. 17
14.2 Plug Lamp Replacement
WARNING!
Disconnect the electrical supply of the hood. Leave
the lamps to cool down first because they could
burn your hands when they are hot.
It indicates the maximum power consumption of the lamp. A lamp
with same power rating should be used when replacing the lamp.
To find out the power rating used in the product,
see the declaration label in the product.
max 50 W
IEC
Fig. 16: Halogen lamp symbol
Fig. 17: Halogen Lamp Replacement
LAMP REPLACEMENT
Plug Lamp Replacement
