11 AIR EXHAUST INSTALLATİON
1- Ø150/120mm Flue Adapter (Option)
2- 2x 3.5x9.5 Screw
3- Ø120/150mm Plastic Flue (Option)
4- Body
Plastik bacayı (3) ürün gövdesine (4) takınız.()
n When required, attach the connection part (1) on the plastic
flue (3) and press firmly.
n Install air exhaust connection of the appliance.
Fig. 12: PLASTIC FLUE CONNEC-
TION
AIR EXHAUST INSTALLATİON
28.12.2017 HOOD USER GUIDE ENGLISH 21
