SYSTEM OPERATIONS-16
DC PANEL
The right side of the AC/DC Panel is the DC Section.
At the top of the DC Section are four (4) breakers;
two (2) breakers on the right and two (2) breakers
on the left.
Breakers on the Left:
Helm Accessory - The DC Power comes from the
battery switch to this breaker. From this breakers
the power goes to the Helm Accessory Switches
at the Helm. All power to the Helm Switches can
be turned ON and OFF at this breaker.
Main Battery 1 - The DC Power comes from the
battery switch to this breaker. From this breaker
the power goes to all breakers directly below
this breaker. All power to the left hand column
of breakers can be turned ON and OFF from
this breaker.
Breakers on the Right:
Bridge Electric - The DC power goes from the
battery switch to this breaker. From this breaker
the power goes the Bridge.
Activating the DC Power
There are two (2) sets of switches that must be ON
to activate the DC Power on your 33C. One set of
switches are the battery switches located by the
entry door in the Salon. The other set of switches
are the Main Breakers on the AC/DC Panel. On the
DC section of the AC/DC Panel are two columns of
breakers. Each Main Breaker controls that column
of switches below it. To supply power to one of the
switches listed on the left side of the panel, the Main
Breaker on the left hand side must be on.
Fuel fumes in the engine compartment can ex-
plode. Before working on any electrical wiring,
ventilate the engine compartment and disconnect
the batteries to prevent sparking.
•
•
•
NEVER reset a breaker switch, which has tripped
automatically, without fi rst locating and cor-
recting the problem. The electrical system and
devices may be damaged.
Alterations or extensions to the electrical sys-
tem can cause electrical shock or fi re. ONLY
competent marine electricians should make
system changes according to U.S. Coast Guard
regulations.
FUSE BLOCK - Salon
There is a Fuse Block located behind the AC/DC
Panel. There is also a FUSE CARD located on the
wall by the Fuse Block. This card will indicate all
fuse positions and size of fuses. Remember, there
are memory sections (constantly ON) of the Fuse
Block.
FUSE BLOCK - Bridge
There is also a Fuse Block behind the Helm. The
fuse card behind the DC Panel has the location and
size information for these fuses. Remember, there
are memory sections (constantly ON) of the Fuse
Block.
Turn off all electric power to your AC/DC Panel
when opening the door to the electrical cabinet.
The power can be turned off by the two (2) Main
DC Switches at the top of the panel, and the Main
AC Switch in the AC portion of the Panel. In addi-
tion, make sure to remove all Shore Power Cords,
and shut down the Generator. Do not forget the
breaker for the memory.
