SIMAG SDE Series - Using the Appliance; Starting the Appliance

8
F02
2
5
ON
ON
1
ON / I
OFF / 0
4
6
3
F03
Serial number XX 123456
x A
CI. T
Type
IP xx Rxxx x,xx kg x,xxx t Co
2
eq.
2103
xx Hz xxx W xx A
230 V ~
ABC 123 AS 230/50/1 Rxxx
This appliance can be used by children aged 8 and over and by people with reduced physical, sensory or mental
abilities or with a lack of experience and knowledge only if they have been adequately instructed and supervised in
the safe use of the appliance and have learned the possible dangers derived from its use.
F02
Starting the appliance
1
Power the appliance inserting its plug into a socket with adequate capacity and turning the switch that
powers the socket to ON or, if the appliance has been connected to an electrical panel, set the main switch of
the panel to ON: the appliance is now powered up.
2
Open the water supply tap so that it can be lled from the appliance.
USING THE APPLIANCE
only for machines with
water condensation
opening the water supply tap
depending on the models, inserting
the appliance plug or turning on
the main switch of the dedicated
panel: now the appliance is powered
Current intensity
Frequency
Degree of protection
Climate class
Coolant data
Supply voltage
Supply fuse
Maximum power
Certications
Production date
for instance 2103
21: year | 2021
03: month | March
Manufacturer Logo
and company name
MODEL
SERIAL NUMBER
