SPECIFICATIONS
ice making capacity
ELECTRONIC MODULAR SUPERFLAKER
MODEL SPN 1205
Important operating requirements:
MIN MAX
• Air temperature 10°C (50°F) 40°C (100°F)
• Water temperature 5°C (40°F) 35°C (90°F)
• Water pressure 1 bar (14 psi) 5 bars (70 psi)
• Electr. voltage
• variations from voltage
• rating specified
• on nameplate -10% +10%
NOTE. The daily ice-making capacity is directly related to the condenser air inlet temperature, water
temperature and age of the machine.
To keep your S IMA G FLAKER at peak performance levels, periodic maintenance checks
must be carried out as indicated on page 41 of this manual.
Page 10
1150
1100
1050
1000
950
900
850
800
750
700
Kg.
32 °C21 15 10
°C
10
21
o
32
38
1400
1300
1200
1100
1000
900
800
700
600
500
Kg.
°C
°C
DE 10 A 38°C
o
32
38
AIR COOLED MODEL
WATER TEMPERATURE
AMBIENT TEMPERATURE
ICE PRODUCED PER 24 HRS.
WATER COOLED MODELS
WATER TEMPERATURE
AMBIENT TEMPERATURE
ICE PRODUCED PER 24 HRS.
27 32 21 15 1027
