5. Unsolder and disconnect the capillary tube
and the accumulator/suction line assy from the
outlet line of the freezing cylinder.
6. Remove the three/four bolts and washers
securing the gear reducer base to the unit chassis,
then remove bolts and lockwashers which attach
the bottom of the aluminium adaptor to the gear
reducer case cover.
7. Lift the freezer up and off the gear motor
assembly, then if necessary remove the
aluminium adaptor by removing the three
mounting screws and lockwashers.
NOTE. It is imperative to install a replacement
drier whenever the sealed refrigeration
system is open.
Do not replace the drier until all other repairs
or replacements have been completed.
8. To install the replacement evaporator follow
the above steps in reverse.
NOTE. Thoroughly evacuate the system to
remove moisture and non condensables after
evaporator replacement.
N. REPLACEMENT OF AIR COOLED
CONDENSER
1. Remove front/top and side/rear panels on
models SP125-255, SPN405 and top SPN 605 and the
front and right side panel on model SPN 1205.
2. Remove from the condenser fins the
condenser ambient temperature sensor probes.
3. Remove the two bolts attaching the
condenser to the base.
4. Recover the refrigerant from the system
and transfer it in a container so to reclaim or
recycle it.
5. Unsolder the refrigerant lines from the
condenser and remove it from the unit.
NOTE. It is imperative to install a replacement
drier whenever the sealed refrigeration
system is open.
Do not replace the drier until all other repairs
or replacements have been completed.
6. To install the replacement condenser follow
the above steps in reverse.
NOTE. Thoroughly evacuate the system to
remove moisture and non condensables after
condenser replacement.
3. On the models SP125-255, SPN405-605
remove the bolts securing the fan motor bracket
to the cabinet base and then remove the
assembly.
On model SPN1205 unloose, with an allen key, the
screw securing the fan blade hub to the fan motor
shaft then unscrew the bolts holding the fan
motor to its protection grid.
4. To install the replacement fan motor follow
the above steps in reverse.
NOTE. When installing a new fan motor
check that the fan blades do not touch any
surface and move freely.
L. REPLACEMENT OF DRIER
1. Remove the front/top and side/rear panels
on models SP125-255, SPN405-605 and the
front panel on model SPN1205.
2. Recover the refrigerant from the system
and transfer it in a container so to reclaim or
recycle it.
3. Unsolder the refrigerant lines from the two
ends of the drier (the capillary tube from one side
on SP255).
4. To install the replacement drier remove
factory seals and solder the refrigerant lines and
the capillary tube taking precautions to NOT
OVERHEAT the drier body.
5. Thoroughly evacuate the system to remove
moisture and non condensable after drier
replacement.
6. Charge the system with proper refrigerant
by weight (see data plate of machine) and check
for leaks.
7. Replace panels previously removed.
M. REPLACEMENT OF THE FREEZING
CYLINDER
1. Follow the steps at item H to remove the ice
spout.
2. Remove the clamp fastening the water hose
to the water inlet port of the freezer assy. Place
a water pan under this water inlet port then
disconnect the water hose and collect all water
flowing from freezer and from water hose.
3. Withdraw the evaporator sensor probe from
the its holder as stated in item B.
4. Recover the refrigerant from the system
and transfer it in a container so to reclaim or
recycle it.
