5 Operation
5.1 Function of displays
A. The main display shows the selected time or temperature for heating.
Display Indication
t time in minutes
°C temperature in degrees Celsius
°F temperature in degrees Fahrenheit
B. The power display shows the selected power setting.
Display Indication
• 20% power
•• 40% power
••• 60% power
•••• 80% power
••••• 100% power
5.2 Function of buttons
Button Function
POWER Press to adjust the power in steps of 20%. The selected
power is indicated on the power display.
MODE Press to switch between TIME MODE and TEMP MODE.
UP (+) Press to increase the value shown on the main display.
DOWN (-) Press to decrease the value shown on the main display.
START/STOP Press to start or stop the heater. The LED on the START/
STOP button is lit when the heater is heating and flashes
during temperature measurement.
