3 Installation of mains plug
Due to the many types of mains plugs, no mains plug is supplied with
the IH 070/090. A qualified electrician must install a suitable mains plug.
The correct supply voltage is shown in section 2.2.
The wires should be connected as follows:
IH 070
Colour of IH 070 wire Mains supply terminal
yellow/green Protection earth (PE)
brown Phase 1 (L1)
blue Neutral (N)
Connect the IH 090 to only two of the three phases. Verify that the
correct circuit breaker is installed. See section 2.2 for circuit breaker
specifications.
IH 090
Colour of IH 090 wire Mains supply terminal
yellow/green Protection earth (PE)
brown Phase 1 (L1)
bluw Phase 2 (L2)
