smart mounting
®
26 Induction Heater IH 070/090 © simatec ag
IH 090
Voltage (± 9%): 400 V / 50 Hz
440–480 V / 60 Hz
575 V / 60 Hz
Recommended circuit protection 20A circuit breaker
Power consumption (maximum) 6,4kVA (400 V / 50 Hz)
7,4kVA (440–480 V / 60 Hz)
9,2kVA (575 V / 60 Hz)
Temperature control 0–250°C (32-482°F) in steps of 1°
Probe maximum temperature 250°C (482°F)
Time mode 0–60 minutes in steps of 0.1 minute
Power range 20–100% in steps of 20%
Demagnetisation, automatic Residual magnetism < 2A/cm
Overall dimensions 420 x 280 x 420mm
Area between supports 145 x 205mm
Coil diameter 115mm
Weight (with yokes) 38kg
Workpiece maximum weight Bearing 120kg, solid component 60kg
Maximum heating temperature approx. 400°C (752°F)
Standard yoke dimensions 55 x 55 x 275mm (for
Ø of 78mm)
28 x 28 x 275mm (for
Ø of 40mm)
14 x 14 x 275mm (for
Ø of 20mm)
