AS3260 DD700 ROLL ASSEMBLY - 5.5m RH
ITEM PART NO DESCRIPTION QTY COMMENTS
1
AS0776 AXLEASSEMBLY-DD7006RINGS 2
2 P02008 NUTLOCKM16'TYPET' 14 DIN985
3 P02037 WASHERSPRINGM12 22
4 P02602 WASHERFLATM16 14
5 P04179 WASHERFLATM12Ø38 22
6 P06802 BOLTUM16GR8.8190x117 7
7 P09558 SCRAPERPLATE 10
8 P09559 SCRAPERSTEMRH 5
9 P09560 SCRAPERSTEMLH 2
10 P10029 SCRAPER11/2 1 J220112460
11 P10870 BOLTM12x30GR.8.8 22
