Simba X-Press - Following Harrow Operation; Air Brake Coupling Procedure

X-Press
Operating Instructions
18
2.5.3 Following Harrow
Operation
Into Work:
1. Arrive in field and unfold machine
accordingtooperatinginstructions
2. Whilstatrearofmachineclosingaxle
tapsmovePins(qty2)fromfrontmost
holes(bylug)torearhole.
3. Removepin on outerquadrant plate
andre-positioninthehighestpossible
holeforstorage.
4. Drivingforwardwilliptheharrowout
intoaworkposition
5. Whenturninginwork,tipthemachine
rearwards into the roll.  Reversing
the machine in this position allows
theharrowtoiptemporarilyintothe
transport position.  Driving forwards
againipstheharrowbackintowork.
Turninginworkmustonlybeon
theDD700rearroll.Attemptingto
lowerthetransportaxlewiththe
harrow in the work position will
seriously damage the following
harrowcomponents.
Into Transport:
1. TilttheX-Pressontotherearrolland
reverse the machine slightly as if
performingaheadlandturn.
2. Whilst at the rear of the machine
openingthetransportaxletaps,move
theharrowclamppins(qty2)fromthe
frontholestotherearholesbythelugs.
3. Usethepinintheouterquadrantplate
tothelowestpositionpermittedthatit
willlocktheharrowarmdown.
4. Continue folding the X-Press in
accordance with the operating
instructions.
2.6 Air Brake Coupling
Procedure
Pleaserefertothefollowingprocedurewhen
couplingordecouplinganyitemofSIMBA
machineryttedwithanAIRbrakeorAIR
and HYDRAULIC brake system. Please
notethatthisproceduredoesnotapplyto
any machines tted with a HYDRAULIC
systemONLY.
2.6.1 When Coupling
1. Reverse up to the machine and
connectthemachinetothetractoras
instructedtoinSection2.4.1.
2. With the machine connected couple
theairlines.Whencouplingensurethe
yellowlineisattachedrstfollowedby
theredline.
3. Your brake hoses are now attached
andarereadyforoperation.
4. Continuewiththecouplingprocessas
instructedinSection2.4.1.
2.6.2 When De-coupling
1. Bring the machine to the parking
positionasinstructedtoinSection2.9.
2. With the machine still connected to
thetractorremovetheredbrakeline
followedbytheyellowline.
