AS4195 ROLL UNIT RH - 4.6m - DDL600 - 150
ITEM PART NO DESCRIPTION QTY COMMENTS
1
AS4194 SCRAPERASSEMBLY DDL150 14
2 P01834 BEARINGSCJ50 2
3 P02007 NUTLOCKM12 8
4 P02008 NUTLOCKM16'TYPET' 4
5 P02009 NUTLOCKM20 8
6 P02601 WASHERFLATM12 8
7 P02602 WASHERFLATM16 4
8 P02603 WASHERFLATM20 8
9 P05030 SCREWM12x55CSKGR10.9 8
10 P05617 SCREWM12x65CSKGR10.9 8
11 P06802 BOLTUM16GR8.8190x117 2
12 P12758 STUBAXLEENDWASHERØ50 2
13 P12950 BOLTM12x35SOCKETCAP 4
14 P13377 RETAININGPLATE 2
15 P15186 DD600RING-275BORE 30
16 P15411 BOLTM20x80GR10.9CSK 8
17 P15638 1/8THBSPGREASENIPPLE45° 2
18 P16163 15MMENDSPACERRING 1
19 P16237 ROLLTUBE-2280mm 1
20 P16371 ENDSPACERRING20mm 1
21 P16678 DDL600SPACER8X58MM 15
22 P16707 INTRNLSPACER86X8M 15
23 P17831 PILLARRH-FORP01834 1
24 P17832 PILLARLH-FORP01834 1
25 P17834 SCRAPERRAIL-2300mm 1
