Simba X-Press - Page 129

129X-Press
Operating Instructions
7.PartsandAssembly
AS4194 SCRAPER ASSEMBLY DDL150
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P01281 BOLTM12x100GR.8.8 2
2 P02007 NUTLOCKM12 2
3 P02600 WASHERFLATM10 4
4 P02601 WASHERFLATM12 2
5 P05534 NUTLOCKM10 2
6 P12778 BOLTM10x45GR8.8 2
7 P17914 SCRAPERSTEM 1
8 P17916 SCRAPERSTEMCLAMPPLATE 1
9 P17956 SCRAPERPLATE150MM 1
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
