7.PartsandAssembly
AS2982
ITEM PART NO DESCRIPTION QTY COMMENTS
1
P02263 DOWTYSEAL½"BSP 1
2 P03686 ADAPTORMALE-MALE½"-3/8"BSP 1
3 P09318 TADAPTOR3/8"BSP 1
4 P10128 QRC-BRAKE 1
5 P13248 BRAKECHAMBEROIL/AIR 2
6 P15544 HA1/4"X7900mm 1
7 P15545 HA1/4"X1235mm 2 90°SWEEPBOTHENDS
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
HOSE LAYOUT - HYDRAULIC BRAKES
