AS2158 LIFT CIRCUIT - HYD. COMPONENT LAYOUT
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2359 REARDRAWBARHYDRAULICS 1
2 P00071 NIPPLE-GREASE 4
3 P00203 ADAPTORMALE-MALE½"BSP 4
4 P00205 QUICKRELEASEMALE-½"BSP 2
5 P00206 ADAPTORMALE-FEM½"BSP 2
6 P00774 SHUTOFFTAP½"BSP 2
7 P02263 DOWTYSEAL½"BSP 8
8 P02735 BULKHEAD½"BSP 2
9 P03686 ADAPTORMALE-MALE½"-3/8"BSP 4
10 P03687 DOWTYSEAL3/8"BSP 4
11 P06216 ADAPTORTSFOR½"BSP 2
12 P06217 ADAPTORTSFOE½"BSP 2
13 P12888 CYLINDERØ120x310 1 580-890
14 P12894 CYLINDERØ120x310 1 580-890
15 P14172 BLANKINGCAP1/2" 2
