Simba X-Press - Page 159

159X-Press
Operating Instructions
7.PartsandAssembly
AS2748 WING CIRCUIT - HYD. COMPONENTS
ITEM PART NO DESCRIPTION QTY COMMENTS
1
AS2358 REARDRAWBARHYDRAULICS 1
2 P00203 ADAPTORMALE-MALE½"BSP 11
3 P00205 QUICKRELEASEMALE-½"BSP 2
4 P02263 DOWTYSEAL½"BSP 13
5 P02733 ELBOW1/2"BSP-F-F 1
6 P02735 BULKHEAD½"BSP 2
7 P03686 ADAPTORMALE-MALE½"-3/8"BSP 6
8 P03687 DOWTYSEAL3/8"BSP 10
9 P06217 ADAPTORTSFOE½"BSP 4
10 P06219 BLANKINGPLUG½"BSP 5
11 P06268 BLANKINGPLUG-1/4"BSP 1
12 P07977 BLANKINGPLUG3/8"BSP 3
13 P08516 GAUGEADAPTOR¼"BSP 1
14 P08838 ACCUMULATOR1.4LDIAPHRAGM10b 1
15 P09116 GAUGEADAPTER1/4"x1/4"BSP 1
16 P09117 PRESSUREGAUGE250BAR 1
17 P11785 ACCUMULATOR0.7L10BAR 1
18 P12056 DOC+PRRED.MANIFOLD 1 J933499082
19 P12786 CYLINDER-Ø90x400-45 2 673-1073
20 P14090 CONNECTORBLOCK3/8"BSP 1
21 P14172 BLANKINGCAP1/2" 2
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
