Simba X-Press - Page 43

43X-Press
Operating Instructions
7.PartsandAssembly
AS4091 4.6m X-PRESS TOP LEVEL
A
SSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1
AS2157 DISCFRAMEADJUSTERASSEMBLY 2
2 AS2158 LIFTCIRCUIT-HYD.COMPONENTLAYO
U
1
3 AS2748 WINGCIRCUIT-HYD.COMPONENTS 1
4 AS2849 LOADBINDERASSEMBLY530mm 1
5 AS3258 DD700ROLLASSEMBLYRH 1
6 AS3259 DD700ROLLASSEMBLYLH 1
7 AS3806 X-PRESSDRAWBARASSEMBLY 1
8 AS3808 LIFTAXLEASSEMBLY 1
9 AS4088 CHASSISASSEMBLY 1
10 AS4094 DISCFRAMELH-4.6m 1
11 AS4095 DISCFRAMERH4.6m 1
12 AS4100 WINGASSEMBLY-RH4.6m 1
13 AS4101 WINGASSEMBLY-LH4.6m 1
14 AS4145 STICKERKITX-PRESS4.6m 1
15 P17897 MANUAL-TRAILEDX-PRESS2011 1
