49X-Press
Operating Instructions
7.PartsandAssembly
AS3806 X-PRESS DRAWBAR ASSEMBLY
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00002 BOLTUM12GR8.870x54 4
2 P00045 BOLTM36x200GR.8.8 2
3 P02007 NUTLOCKM12 18
4 P02012 NUTLOCKM36 2
5 P02483 LYNCHPINCAT1 1
6 P02600 WASHERFLATM10 2
7 P02601 WASHERFLATM12 24
8 P02604 WASHERFLATM24Ø50 4
9 P02609 WASHERFLATM39 2
10 P03089 BOLTM12x65GR.8.8 2
11 P04754 NUTLOCKM8 8
12 P05400 WASHERFLATM6 6
13 P05492 NUTLOCK1"UNF 2
14 P05534 NUTLOCKM10 2
15 P05535 WASHERFLATM8 16
16 P06651 BOLTM10x25GR.8.8 2
17 P08012 BOLTM12x45GR8.8 8
18 P08548 BOLT1"UNFx7"GR.V 2
19 P08997 HITCH-FRONT 1
20 P09092 HOSESTOWAGEPLATE 1
21 P09112 CLAMP½"BSPPAIR 3
22 P09113 CLAMP-TOPPLATE 2
23 P09597 BOLTM8x25GR.8.8 8
24 P10278 BOLTM8x45GR.8.8 1
25 P12284 X-PRESSDRAWBAR 1
26 P12507 BOLTM8x80GR.8.8 1
27 P13563 NUTPLAINM6 3
28 P14001 HOSEMAST-X-PRESS 1
29 P14029 PINØ30x138 1
30 P15560 LIGHTBOARDFRH 1
31 P15561 LIGHTBOARDFLH 1
32 P16007 SOCKETPLATE12N 1
33 P16360 CAT3-CAT2BUSHINSERT 1
34 P17342 LIGHTARMMOUNT 4
35 P17815 MANUALHOLDER-COMPLETE 1
36 P17900 BOLTM6x25GR.8.8 3
37 P18659 FRONTLIGHTMOUNT 2
