67X-Press
Operating Instructions
7.PartsandAssembly
AS4096 DISC FRAME ASSEMBLY 5.5m LH
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS3210 DISCUNITASSEMBLYRH 11
2 AS3211 DISCUNITASSEMBLYLH 10
3 P00036 BOLTM30x180GR.8.8 2
4 P00874 BOLTM20x70GR.8.8 4
5 P01704 BOLTM16x50GR8.8 43
6 P01901 BOLTM16x80GR.8.8 44
7 P02008 NUTLOCKM16'TYPET' 87 DIN985
8 P02009 NUTLOCKM20 4
9 P02011 NUTLOCKM30 2
10 P02602 WASHERFLATM16 148
11 P02603 WASHERFLATM20 4
12 P02608 WASHERFLATM30 8
13 P11462 DISCBLADEØ515x6 20 5HOLESØ13PCD11
3
14 P12620 TOPPLATE 22
15 P12621 SPACERØ36xØ16.5x31mm 44
16 P12622 TRACKARM 22
17 P12783 LYNCHPINCAT0 22
18 P12810 NUTCASTLEM24 22
19 P12815 BOLTM24x185STRUCTURALGR8.8 22
20 P12886 Ø24xØ16x13mmSPACERBUSH 22
21 P12896 TRACKRODFRONTLH5.5SLX-PRESS 1
22 P14010 DISCFRAME5.5LH 1
23 P14015 TRACKRODREAR 1 11-550mm
24 P14055 SPACERBUSH-10mm 4
25 P14216 DISCBLADEØ457x6 1 5HOLESØ13PCD11
3
26 P15438 ANGLEGUIDE 2
27 P17076 ADJUSTER350-600 2
