Simba X-Press - Page 69

69X-Press
Operating Instructions
7.PartsandAssembly
AS4099 DISC FRAME ASSEMBLY
6.6m RH
ITEM PART NO DESCRIPTION QTY COMMENTS
1
AS3210 DISCUNITASSEMBLYRH 13
2 AS3211 DISCUNITASSEMBLYLH 12
3 AS4148 DISCUNITASSEMBLYTWINLH 1
4 P00036 BOLTM30x180GR.8.8 2
5 P00874 BOLTM20x70GR.8.8 4
6 P01704 BOLTM16x50GR8.8 52
7 P01901 BOLTM16x80GR.8.8 52
8 P02008 NUTLOCKM16'TYPET' 104
9 P02009 NUTLOCKM20 4
10 P02011 NUTLOCKM30 2
11 P02602 WASHERFLATM16 156
12 P02603 WASHERFLATM20 4
13 P02608 WASHERFLATM30 8
14 P11462 DISCBLADEØ515x6 26
15 P12620 TOPPLATE 26
16 P12621 SPACERØ36xØ16.5x31mm 52
17 P12622 TRACKARM 26
18 P12783 LYNCHPINCAT0 26
19 P12810 NUTCASTLEM24 26
20 P12815 BOLTM24x185STRUCTURALGR8.8 26
21 P12821 TRACKRODRHFRONT6.6mX-PRESSSL 1
22 P12886 Ø24xØ16x13mmSPACERBUSH 14
23 P14013 DISCFRAME6.6RH 1
24 P14016 TRACKROD-REAR 1
25 P14055 SPACERBUSH-10mm 4
26 P14216 DISCBLADEØ457x6 1
27 P15438 ANGLEGUIDE 2
28 P17076 ADJUSTER350-600 2
