AS4102 WING ASSEMBLY RH - 5.5m
ITEM PART NO DESCRIPTION QTY COMMENTS
1
P00071 NIPPLE-GREASE 2
2 P01645 BUSHSPRUNG-Ø32xØ26x30 1
3 P02010 NUTLOCKM24 2
4 P02604 WASHERFLATM24Ø50 4
5 P12610 BOLTM24x120GR10.9STR 2
6 P17822 WINGRH-5.5m 1
