Simba X-Press - Page 95

95X-Press
Operating Instructions
7.PartsandAssembly
AS4105 WING ASSEMBLY - LH 6.6m
ITEM PART NO DESCRIPTION QTY COMMENTS
1 P00071 NIPPLE-GREASE 2
2 P01645 BUSHSPRUNG-Ø32xØ26x30 2
3 P02010 NUTLOCKM24 2
4 P02604 WASHERFLATM24Ø50 4
5 P12610 BOLTM24x120GR10.9STR 2
6 P17825 WINGLH-6.6m 1
