AS3259 DD700 ROLL ASSEMBLY LH
ITEM PART NO DESCRIPTION QTY COMMENTS
1
AS0775 AXLEASSEMBLY-DD7005RINGS 2
2 P02008 NUTLOCKM16'TYPET' 10 DIN985
3 P02037 WASHERSPRINGM12 18
4 P02602 WASHERFLATM16 10
5 P04179 WASHERFLATM12Ø38 18
6 P06802 BOLTUM16GR8.8190x117 5
7 P09558 SCRAPERPLATE 8
8 P09559 SCRAPERSTEMRH 1
9 P09560 SCRAPERSTEMLH 4
10 P10029 SCRAPER11/2 1 J220112460
11 P10870 BOLTM12x30GR.8.8 18
